swoc::IPNet Class Reference

#include <IPRange.h>

Collaboration diagram for swoc::IPNet:

Public Member Functions
	IPNet ()=default
	Construct invalid network.
	IPNet (self_type const &that)=default
	Copy constructor.
	IPNet (IPAddr const &addr, IPMask const &mask)
	IPNet (TextView text)
bool	load (swoc::TextView text)
bool	empty () const
IPAddr	min () const
IPAddr	max () const
IPMask::raw_type	width () const
IPMask const &	mask () const
IPRange	as_range () const
bool	is_ip4 () const
bool	is_ip6 () const
sa_family_t	family () const
	Address family of network.
IP4Net	ip4 () const
IP6Net	ip6 () const
self_type &	assign (IPAddr const &addr, IPMask const &mask)
self_type &	clear ()
	Reset network to invalid state.
bool	operator== (self_type const &that) const
	Equality.
bool	operator!= (self_type const &that) const
	Inequality.

Protected Attributes
IPAddr	_addr
	Address and family.
IPMask	_mask
	Network mask.

Detailed Description

Representation of an IP address network.

Definition at line 863 of file IPRange.h.

Constructor & Destructor Documentation

IPNet() [1/2]

swoc::IPNet::IPNet ( IPAddr const & addr, IPMask const & mask )

inline

Construct from addr and mask.

Parameters

addr	An address in the network.
mask	The mask for the network.

The network is based on the mask, and the resulting network address is chosen such that the network will contain addr. For a given addr and mask there is only one network that satisifies these criteria.

Definition at line 2208 of file IPRange.h.

IPNet() [2/2]

swoc::IPNet::IPNet ( TextView text )

inline

Construct from text.

Parameters

text	Network description.

The format must be "addr/mask" where "addr" is a valid address and mask is either a single number for the mask width (CIDR) or a mask in address notation.

Definition at line 2210 of file IPRange.h.

Member Function Documentation

as_range()

IPRange swoc::IPNet::as_range ( ) const

inline

Returns

A range that exactly covers the network.

Definition at line 2240 of file IPRange.h.

assign()

IPNet::self_type & swoc::IPNet::assign ( IPAddr const & addr, IPMask const & mask )

inline

Assign an addr and mask to this.

Parameters

addr	Network addres.
mask	Network mask.

Returns

this.

Definition at line 2245 of file IPRange.h.

clear()

auto swoc::IPNet::clear ( )

inline

Reset network to invalid state.

Definition at line 2292 of file IPRange.h.

empty()

bool swoc::IPNet::empty ( ) const

inline

Returns

true if the network contains no addresses (is invalid).

Definition at line 2215 of file IPRange.h.

family()

sa_family_t swoc::IPNet::family ( ) const

inline

Address family of network.

Definition at line 928 of file IPRange.h.

ip4()

IP4Net swoc::IPNet::ip4 ( ) const

inline

Returns

The network as explicitly IPv4.

Definition at line 2282 of file IPRange.h.

ip6()

IP6Net swoc::IPNet::ip6 ( ) const

inline

Returns

The network as explicitly IPv6.

Definition at line 2287 of file IPRange.h.

is_ip4()

bool swoc::IPNet::is_ip4 ( ) const

inline

Returns

true if network is IPv4.

Definition at line 916 of file IPRange.h.

is_ip6()

bool swoc::IPNet::is_ip6 ( ) const

inline

Returns

true if network is IPv6.

Definition at line 922 of file IPRange.h.

load()

bool swoc::IPNet::load

(

swoc::TextView

text

)

Parse network as text.

Parameters

text	String describing the network in CIDR format.

Returns

true if a valid string, false if not.

Definition at line 897 of file swoc_ip.cc.

mask()

IPMask const & swoc::IPNet::mask ( ) const

inline

Returns

The mask for the network.

Definition at line 2235 of file IPRange.h.

max()

IPAddr swoc::IPNet::max ( ) const

inline

Returns

Largest address in the network.

Definition at line 2225 of file IPRange.h.

min()

IPAddr swoc::IPNet::min ( ) const

inline

Returns

Network address - smallest address in the network.

Definition at line 2220 of file IPRange.h.

operator!=()

bool swoc::IPNet::operator!= ( IPNet::self_type const & that ) const

inline

Inequality.

Definition at line 2257 of file IPRange.h.

operator==()

bool swoc::IPNet::operator== ( IPNet::self_type const & that ) const

inline

Equality.

Definition at line 2252 of file IPRange.h.

width()

IPMask::raw_type swoc::IPNet::width ( ) const

inline

Returns

The number of bits in the mask.

Definition at line 2230 of file IPRange.h.

Member Data Documentation

_addr

IPAddr swoc::IPNet::_addr

protected

Address and family.

Definition at line 956 of file IPRange.h.

_mask

IPMask swoc::IPNet::_mask

protected

Network mask.

Definition at line 957 of file IPRange.h.

---

The documentation for this class was generated from the following files:

• IPRange.h
• swoc_ip.cc
